Page 9
9
PARTS GUIDE (ZR-4630)
LED Zone ON/OFF Indicator
Zone Label Slots
Tuner Controls
DB-9 Computer
Interface
Sensor for Capturing
IR Commands
Zone All On/Page
Enable Switches
Programming Controls
and Indicators
Tuner Display
Removable Programming Cover
Main Power Switch
Sync
Inputs
Keypad Inputs
System
Expansion
Paging
Input
Flasher Outputs
IR
Input
12V Control
Output
Tuner Antenna
Inputs
Audio
Inputs
Individual Zone
Preamplifier Output
Gold plated, dual banana plug
spaced, five-way speaker
binding posts
Removable
Power Cord Socket
Fixed/Variable Preamplifier
Adjustment Switch
Figure 1
