18 Product description
• System Monitor
• PDU
Pedestal (one per column)
• Blower unit
• Thermostat harness Top cap (one per column)
• Air probe harness
CS 1000M SG and Meridian 1 PBX 61C CP PIV
The CS 1000M SG and the Meridian 1 PBX 61C CP PIV are dual-CPU
systems with standby processing capability, fully redundant memory, and a
full-network group. Two cPCI Core/Network modules and one IPE module
are required. Additional IPE modules and application modules can be used.
Figure 3 "Meridian 1 PBX 61C CP PIV or Meridian 1 Option 61C" (page
19)
illustrates an Option 61C or Meridian 1 PBX 61C CP PIV.
With the addition of a Signaling Server, Option 61C or Meridian 1 PBX
61C CP PIV becomes CS 1000M SG.
Figure 4 "CS 1000M SG" (page
19) illustrates a CS 1000M SG.
