780i 3-Way SLI Motherboard

NVIDIA Corporation

50

October 17, 2007 | DU-03597-001_v01

System Voltages

Select

System Voltages

from the Advanced Chipset Features menu and press

Enter

to display the System Voltages menu.

Figure 12. System Voltages Menu

q

CPU Core

Use the

Page Up

and

Page Down

keys to scroll through the voltages or select

[Auto]

to automatically set the voltage level for the CPU Core.

q

CPU FSB
Use the

Page Up

and

Page Down

keys to scroll through the voltages or select

[Auto]

to automatically set the voltage level for the CPU FSB.

q

Memory
This function defines the voltage level for the DRAM. Use the

Page Up

and

Page Down

keys to select a voltage or select

[Auto]

to automatically set the

voltage.

#$"!:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help

F5: Previous Values F7:Defaults

Parameters

Settings Current Value

CPU Core

[

Auto

]

1.28

CPU FSB

[Auto]

1.2V

Memory

[Auto]

1.85V

nForce SPP

[Auto]

1.30V

nForce MCP

[Auto]

1.50V

HT nForce SPP <-> MCP

[Auto]

1.20V

nForce MCP Auxiliary

[Auto]

1.50V

GTLVREF Lane 0

[Auto]

+00mv

GTLVREF Lane 1

[Auto]

+00mv

GTLVREF Lane 2

[Auto]

+00mv

GTLVREF Lane 3

[Auto]

+00mv

Item Help

Main Level

}}


Voltage level for CPU
Core (CPU VID)

Phoenix – AwardBIOS CMOS Setup Utility

System Voltages
