Packard Bell EasyNote T5 Disassembly Manual
Page 7
Removing the Keyboard Cover
To remove the Keyboard Cover , first remove the battery (see
Removing the Battery
), then
perform the following steps:
1. Remove the screw as shown in Fig. 6
Fig. 6 Removing Keyboard Cover screws
2. Remove the Keyboard Cover as shown in Fig. 7
Fig. 7 Removing the Keyboard Cover
Removing the Keyboard
To remove the Keyboard module, first remove the keyboard cover (see
Removing keyboard
cover
), then perform the following steps:
M2x15 Black
