Page 10
Packard Bell EasyNote T5 Disassembly Manual
Page 10
Fig. 12 Removing Heat plate from base unit
Note: When assembling the heat plate, make sure that these three hocks on the heat plate are properly
inserted into the openings located on the top cover.
Removing the Memory Module
To remove the memory module, first remove the Keyboard cover (see
Removing the keyboard
cover
), remove the keyboard (see
Removing the keyboard
), remove heat plate (see
Removing
heat plate
) then perform the following steps:
1. Unclip memory module as shown in Fig. 13
Fig. 13 Removing the memory module
2. Remove the Memory Module from its slot and put it aside.
Removing the Wireless Module
To remove the Wireless Module, first remove the keyboard cover (see
Removing the keyboard
cover
), remove the keyboard (see
Removing the keyboard
), remove the heat plate (see
