Packard Bell EasyNote T5 Disassembly Manual
Page 19
1. On the other side of the top cover unscrew the two screws on the Touch Pad assembly as
shown in Fig. 30 and remove the Touch Pad assy from the palm rest.
Fig. 30 Touch Pad Assembly
Removing the DC/DC Board
To remove the DC/DC board, first remove the Top Cover (see
Removing the Top Cover
), then
perform the following steps:
1. Remove the screw on the DC/DC board as shown in Fig. 31
M2x3.5 Silver
