Packard Bell EasyNote T5 Disassembly Manual
Page 12
Fig. 16 Removing the heat sink
3. Use flat screws driver to release the CPU from the CPU socket; carefully lift up the CPU and
put it in a safe place.
Fig. 17 Releasing the CPU
Removing the LCD Module
To remove LCD Module, first remove the Keyboard Cover (see
Removing the keyboard cover
)
then remove the keyboard (see
Removing the keyboard
):
1. Unscrew the two LCD connector screws and also, disconnect the speaker connector as
