Specifications

Appendix A

DAQCard-700 User Manual

A-2

© National Instruments Corporation

Dynamic Characteristics

Settling time

±

0.024% accuracy

(

±

1 LSB) for full-scale step ............................................

25

µ

s max at

±

10 V,

±

5 V

10

µ

s at

±

2.5 V (RSE)

System noise ...........................................................................

0.5 LSB rms at

±

5 V range

Stability

Recommended warm-up time ................................................

15 min

Onboard calibration reference

Level ...............................................................................

3.0 V (

±

0.2 mV)

Temperature coefficient ..................................................

60

ppm/

°

C max

Digital I/O

Number of channels ...............................................................

8 input and 8 output

Compatibility .........................................................................

TTL

Digital logic levels .................................................................

Level

Min

Max

Input low voltage

0 V

0.8 V

Input high voltage

2 V

5 V

Input low current
(Vin = 0 V)

-50

µ

A

Input high current
(Vin = 5 V)

1

µ

A

Output low voltage

(Iout = 4 mA)

0.4 V

Output high voltage

(Iout = 4 mA)

3.7 V

Timing I/O

Number of channels ...............................................................

3 counter/timers (1 dedicated to analog input)

Resolution...............................................................................

16

bits

Compatibility .........................................................................

TTL, gate and source pulled high with 100 k

resistors

Base clocks available .............................................................

1 MHz

Base clock accuracy ...............................................................

±

0.01%

Max source frequency ............................................................

10 MHz

Min source pulse duration ......................................................

50 ns

Min gate pulse duration..........................................................

50 ns

Data transfers .........................................................................

Programmed

I/O

Bus Interface

Type .......................................................................................

slave
