9-16 Administration Guide
IP Parameters (Default Profile) screen
If you are using RFC1483 datalink encapsulation, the IP Parameters (Default Profile) screen allows you to
configure various IP parameters for SDSL connections established without an explicitly configured connection
profile:
For most DSL links, Network Address Translation (NAT) is disabled by default in the Default Profile, unless you
use HDLC (Copper Mountain) operation Mode with RFC1483 as the data link encapsulation method. You can
enable it by toggling to Yes.
If you use HDLC (Copper Mountain) operation Mode with RFC1483 as the data link encapsulation method, NAT
is enabled by default, as shown below.
For details on setting up IP Parameters see
IP Parameters (Default Profile)
Address Translation Enabled: No
Filter Set (Firewall)...
Remove Filter Set
Receive RIP: Both
Transmit RIP: Off
Return/Enter accepts * Tab toggles * ESC cancels.
IP Parameters (Default Profile)
Address Translation Enabled: Yes
NAT Map List...
NAT Server List...
Filter Set (Firewall)...
Remove Filter Set
Receive RIP: Both
