WAN and System Configuration 9-15
The WAN Default Profile
If you are using RFC1483 datalink encapsulation, the WAN Default Profile screen controls whether or not the
SDSL link will come up without an explicitly configured connection profile. (PPP datalink encapsulation does not
suppor t a default profile, and the corresponding menu item is unavailable.) See
for more information.
You access the Default Profile screen from the Main Menu by selecting WAN Configuration and then selecting
Default Profile.
The Default Profile screen appears.
■
You can set Must Match a Defined Profile item to Yes or No (the default). This item controls whether or
not the SDSL link will come up without an explicitly configured connection profile. If your ISP is ser ving you
a dynamic IP Address, you need not explicitly configure a connection profile, and the default behavior of the
device will be to connect automatically once it is powered on.
■
If you select IP Parameters the IP Parameters screen appears (see
“IP Parameters (Default Profile) screen”
). This screen allows you to configure various IP parameters for SDSL connections established
without an explicitly configured connection profile.
Main
Menu
WAN
Configuration
WAN
Default Profile
WAN Default Profile
Must Match a Defined Profile: No
IP Parameters...
Return/Enter accepts * Tab toggles * ESC cancels.
Configure Default WAN Connection Parameters here.
