ReadyNAS Pro Business Edition User Guide
1-4
Getting Acquainted
v1.3, November 2008
Introducing the Status Displays, Ports, and Drive Bay
This section introduces the ReadyNAS Pro display, ports, and drive bay.
Front and Side Panel
1. OLED display, including the disk activity status light
2. CPU exhaust vent
3. Power button/power status
4. USB backup status light
5. Backup button
6. Front USB port
7. Drive bay door
Figure 1-1
1
2
3
4
7
5
6
