Reference Manual for the ADSL Modem Wireless Router DG834GSP
Virtual Private Networking 8-31
v1.0, June 2007
Figure 8-29: Running a Ping test to the LAN from the PC
This will cause a continuous ping to be sent to the first DG834GSP. After between several
seconds and two minutes, the ping response should change from “timed out” to “reply.”
Once the connection is established, you can open the browser of the PC and enter the LAN IP
address of the remote DG834GSP. After a short wait, you should see the login screen of the
Modem Router (unless another PC already has the DG834GSP management interface open).
• Gateway-to-Gateway Configuration—test the VPN tunnel by pinging the remote network
from a PC attached to the DG834GSP.
a. Open command prompt (i.e., Start -> Run -> cmd).
Note: Use Ctrl-C to stop the pinging.
Figure 8-30
