or Anti-lock brake warning light Low washer fluid warning light
AWD (All wheel drive) LOCK indicator
light (AWD models)
AWD (All wheel drive) warning light
(AWD models)
Seat belt warning light High beam indicator light (Blue)
or Brake warning light Supplemental air bag warning light Malfunction indicator lamp (MIL)
Charge warning light
Low tire pressure warning light (if so
equipped)
Security indicator light
Door open warning light Cruise main switch indicator light Slip indicator light (if so equipped)
Engine oil pressure warning light Cruise set indicator light Turn signal/hazard indicator lights
Low fuel warning light
CVT (Continuously variable transmission)
indicator light Vehicle dynamic control off indicator light
(if so equipped)
CHECKING BULBS
Apply the parking brake and turn the ignition key
to ON without starting the engine. The following
lights will come on:
, or , , ,
The following lights come on briefly and then go
off:
, or , , , ,
,
If any light fails to come on, it may indicate a
burned-out bulb or an open circuit in the elec-
trical system. Have the system repaired
promptly.
WARNING LIGHTS
or Anti-lock brake
warning light
After turning the ignition key to the ON position,
the light will illuminate. The light will turn off after
about 2 seconds if the system is operational.
If the light comes on while the engine is running,
it may indicate that the anti-lock brake system is
not functioning properly. Have the system
checked by your NISSAN dealer.
If an abnormality occurs in the system, the
anti-lock function will cease but the ordinary
brakes will continue to operate normally. See
“Anti-lock brake system (ABS)” in the “5. Start-
ing and driving” section for further details.
If the light comes on while you are driving,
contact your NISSAN dealer for repair.
WARNING/INDICATOR LIGHTS
AND AUDIBLE REMINDERS
Instruments and controls 2-9
