Heating (A/C OFF)
The air conditioner does not activate. When you
need to heat only, use this mode.
1. Push the A/C button. (A/C OFF will be
displayed and A/C indicator will turn off.)
2. Turn the temperature set dial to the left or
right to set the desired temperature.
¼ The temperature of the passenger compart-
ment will be maintained automatically. Air
flow distribution and fan speed are also con-
trolled automatically.
¼ Do not set the temperature lower than the
outside air temperature. Otherwise the sys-
tem may not work properly.
¼ Not recommended if windows fog up.
Dehumidified defrosting or defogging
1. Push the FRONT defroster button on.
(The indicator light on the button will come
on.)
2. Turn the temperature set dial to the left or
right to set the desired temperature.
¼ To quickly remove ice from the outside of the
windows, turn the fan speed control knobto
right and set to the maximum position.
¼ As soon as possible after the windshield is
clean, push the AUTO button to return to the
auto mode.
¼ When the front defroster button is
pushed, the air conditioner will automatically
be turned on at outside temperatures above
23°F (−5°C) to defog the windshield, and the
air recirculate mode will automatically be
turned off.
Outside air is drawn into the passenger
compartment to improve the defogging per-
formance.
MANUAL OPERATION
Fan speed control
Turn the fan control button to manually
control the fan speed.
Push the AUTO button to return to automatic
control of the fan speed.
Air recirculation
Push the air recirculation button to recir-
culate interior air inside the vehicle. The indicator
light on the button will come on.
The air recirculation cannot be activated
when the air conditioner is in the front defrosting
mode .
Fresh air
Push the button to draw outside air into
the passenger compartment. The indicator light
on the button will come on.
Automatic intake air control
In the AUTO mode, the intake air will be con-
trolled automatically. To manually control the
intake air, push the air recirculate or fresh
air button. To return to the automatic
control mode, push the indicator-illuminated but-
ton for about 2 seconds. The indicator lights
(both air recirculate and fresh air buttons) will
flash twice, and then the intake air will be
controlled automatically.
Air flow control
Pushing the MODE manual air flow control
button selects the air outlet to:
: Air flows from center and side ventila-
tors.
: Air flows from center and side ventila-
tors and foot outlets.
: Air flows from foot outlets and side
ventilators.
: Air flows from defroster, foot outlets
and side ventilators.
4-18 Display screen, heater, air conditioner and audio systems
