800TL Series Front-End Loader Specifications
Loaders for TN-A/TND-A, TNF/TNF-A & TNS-A Tractors
Page 1 of 7
A
B
C
D
E
F
H
G
LOADER MODEL
810TL
810TL
810TL
810TL
Loader type, NSL or MSL
NSL
MSL
NSL
MSL
TRACTOR FAMILY
TN-A/DA
TN-A/DA
TNF/FA
TNF/FA
TRACTOR MODELS
60-75
60-75
65-95
65-95
Lift capacity @ max. height @ 800 mm, lb. (kg)
2100 (953)
2500 (1134)
2000 (907)
2450 (1111)
Lift capacity @ max. height @ pins, lb. (kg)
3300 (1497)
3200 (1451)
3200 (1451)
3100 (1406)
Lift capacity @ 59 in. high @ 800 mm, lb. (kg)
2400 (1089)
2950 (1338)
2350 (1066)
2850 (1293)
Lift capacity @ 59 in. high @ pins, lb. (kg)
3750 (1701)
3650 (1656)
3600 (1633)
3500 (1588)
Breakout force @ 800 mm, lb. (kg)
2650 (1202)
3200 (1451)
2550 (1157)
3100 (1406)
Breakout force @ pins, lb. (kg)
4200 (1905)
3850 (1746)
4050 (1837)
3750 (1701)
Max. lift height, in. (mm)
(A)
122 (3099)
122 (3099)
125 (3175)
125 (3175)
Max. lift height under level bucket, in. (mm)
(B)
110 (2794)
110 (2794)
113 (2870)
113 (2870)
Clearance w/bucket dumped, in. (mm)
(C)
85 (2159)
85 (2159)
87 (2210)
87 (2210)
Reach @ max. lift height, in. (mm)
(D)
30 (762)
30 (762)
38 (965)
38 (965)
Max. dump angle, degrees
(E)
65
64
61
60
Reach @ ground line, in. (mm)
(F)
86 (2184)
86 (2184)
85 (2159)
85 (2159)
Bucket rollback angle, degrees
(G)
45
45
46
46
Digging depth, in. (mm)
(H)
8 (203)
8 (203)
6 (152)
6 (152)
Raising time, seconds
3.3
3.3
3.9
3.9
Lowering time, seconds
2
2
2.4
2.4
Bucket dump time, seconds
3.5
2.4
4.1
2.8
Bucket rollback time, seconds
2.4
2.4
2.8
2.8
Approx. weight, lb. (kg) (loader w/o bucket)
960 (435)
1115 (506)
945 (429)
1095 (497)
LOADER MODEL
820TL
820TL
820TL
820TL
Loader type, NSL or MSL
NSL
MSL
NSL
MSL
TRACTOR FAMILY
TNS-A
TNS-A
TN-A/DA
TN-A/DA
TRACTOR MODELS
75
75
85-95
85-95
Lift capacity @ max. height @ 800 mm, lb. (kg)
2500 (1134)
2650 (1202)
2500 (1134)
2650 (1202)
Lift capacity @ max. height @ pins, lb. (kg)
3850 (1746)
3300 (1497)
3850 (1746)
3300 (1497)
Lift capacity @ 59 in. high @ 800 mm, lb. (kg)
2850 (1293)
3100 (1406)
2850 (1293)
3100 (1406)
Lift capacity @ 59 in. high @ pins, lb. (kg)
4400 (1996)
3750 (1701)
4400 (1996)
3750 (1701)
Breakout force @ 800 mm, lb. (kg)
3100 (1406)
3300 (1497)
3100 (1406)
3300 (1497)
Breakout force @ pins, lb. (kg)
4850 (2200)
3950 (1792)
4850 (2200)
3950 (1792)
Max. lift height, in. (mm)
(A)
135 (3429)
135 (3429)
133 (3378)
133 (3378)
Max. lift height under level bucket, in. (mm)
(B)
123 (3124)
123 (3124)
121 (3073)
121 (3073)
Clearance w/bucket dumped, in. (mm)
(C)
97 (2464)
97 (2464)
96 (2438)
96 (2438)
Reach @ max. lift height, in. (mm)
(D)
47 (1194)
47 (1194)
25 (635)
25 (635)
Max. dump angle, degrees
(E)
57
56
55
53
Reach @ ground line, in. (mm)
(F)
92 (2337)
92 (2337)
93 (2362)
93 (2362)
Bucket rollback angle, degrees
(G)
46
46
50
50
Digging depth, in. (mm)
(H)
6 (152)
6 (152)
7 (178)
7 (178)
Raising time, seconds
4.1
3.6
4.1
3.6
Lowering time, seconds
2.8
2.2
2.8
2.2
Bucket dump time, seconds
3.5
2.4
3.5
2.4
Bucket rollback time, seconds
...............................................................................................2.4...............................................................................................
Approx. weight, lb. (kg) (loader w/o bucket)
1040 (472)
1195 (542)
990 (449)
1150 (522)
NSL = non self leveling MSL = mechanical self leveling (ss) = SuperSteer
NOTES: Specification based on ASAE (S301.3) and are subject to change without notice.
Dimensional and performance specifications are based on typical tractors and tire sizes.
