New Holland Discbine ®
Disc Mower-Conditioner Specifications
H7450 H7550 H7460 H7560
Page 4of 4
MODEL H7450 H7550 H7460 H7560
DIMENSIONS
Height, transport, ft. in. (m)
6' 8" (2.6) 6' 8" (2.6) 6' 8" (2.6) 6' 8" (2.6)
Height, operating, ft. in. (m) 5' 8" (1.7) 5' 8" (1.7) 5' 8" (1.7) 5' 8" (1.7)
Width, transport, ft. in. (m) .........13' 2" (4.0) with standard drawbar hitch, 2-pt ........ ....15' 9" (4.8) with 2-pt swivel hitch or drawbar swivel hitch ........
swivel hitch or drawbar swivel hitch
Width, operating, ft. in. (m) ..............19' 5" (5.9) with standard drawbar hitch ............. .......................24' 11" (7.6) with 2-pt swivel hitch ..........................
...................21' 3" (6.5) with 2-pt swivel hitch................... ....................23' 3" (7.1) with drawbar swivel hitch ........................
................19' 7" (5.9) with drawbar swivel hitch ...............
Length, transport, ft. in. (m) ..............24' 7" (7.2) with standard drawbar hitch ............. ........................30' 5" (9.3) with 2-pt swivel hitch ...........................
...................26' 5" (8.1) with 2-pt swivel hitch................... ..................29' 5 in. (8.7) with drawbar swivel hitch ......................
................25' 5" (7.4) with drawbar swivel hitch ...............
20' 2" (5.8) 20' 8" (6.3) ........................25' 2" (7.7) with 2-pt swivel hitch ...........................
w/std drawbar hitch w/std drawbar hitch
22' 1" (6.7) 22' 7" (6.9) ....................24' 2" (7.4) with drawbar swivel hitch........................
w/2-pt swivel hitch w/2-pt swivel hitch
21' 1" (6.1) 21' 7" (6.6)
w/drawbar swivel hitch w/drawbar swivel hitch
Weight, operating lbs. (kg) 5,800 (2631) 5,680 (2576) 6,500 (2948) 6,380 (2894)
NOTE: Rear curtain up for transport position on flail units. Windrow shields out for field and transport positions on flail and roll units.
DRIVE.......................................................................................................1000 rpm PTO, enclosed gears and four HB belt......................................................................................
DRIVE PROTECTION...........................................................................................Slip clutch and over-running clutch................................................................................................
TRACTOR REQUIREMENT
.....90 PTO hp (67 kW) or greater with standard Category II ..... ..........100 PTO hp (74.5 kW) or greater with Category III..............
and III drawbar or Category III 3-point hitch. drawbar or Category III 3-point hitch.
......................All models require two remote hydraulic valves capable of 1500 psi (10343 kPa), 7-pin SAE J560 connector for transport lights .....................
Safety begins with a thorough understanding of
the equipment. Always make sure you and
your operators read the Operator’s Manual
before using the equipment. Pay close
attention to all safety and operating
decals and never operate machiner y
without all shields, protective devices
and structures in place.
Design, materials and/or specifications are subject to
change without notice and without liability therefor.
Specifications are applicable to units sold in Canada, the
United States, its territories and possessions, and may
var y outside these areas.
