New Holland Discbine
®
Disc Mower-Conditioner Specifications
H7220 H7320 H7230 H7330
Page 2 of 4
MODEL
H7220
H7320
H7230
H7330
DIMENSIONS
Height, transport, ft. in. (m)
5' 8" (1.7)
5' 8" (1.7)
5' 8" (1.7)
5' 8" (1.7)
Height, operating, ft. in. (m)
4' 5" (1.3)
4' 5" (1.3)
4' 5" (1.3)
4' 5" (1.3)
Width, transport, ft. in. (m)
..............9' 11" (3.0) with standard drawbar hitch .............
..................11' 3" (3.4) with standard drawbar hitch ......................
Width, operating, ft. in. (m)
............14' 10" (4.52) with standard drawbar hitch ...........
..................16' 0" (4.6) with standard drawbar hitch ......................
Length, transport, ft. in. (m)
..............17' 7" (5.3) with standard drawbar hitch .............
..................17' 7" (5.3) with standard drawbar hitch ......................
Length, operating, ft. in. (m)
17' 2" (5.2) with standard
17' 2" (5.2) with standard
17' 2" (5.2) with standard
17' 8" (5.4) ) with standard
drawbar hitch
drawbar hitch
drawbar hitch
drawbar hitch
Weight, operating lbs. (kg)
3,690 (1674)
3,740 (1696)
4,165 (1889)
4,065 (1844)
NOTE: Rear curtain up for transport position on flail units. Windrow shields out for field and transport positions on flail and roll units.
DRIVE
........540 rpm PTO, enclosed gears and four HB belt........
......540 or 1000 rpm PTO, enclosed gears and four HB belt..........
DRIVE PROTECTION...........................................................................................Slip clutch and over-running clutch................................................................................................
TRACTOR REQUIREMENT
.........65 PTO hp (48 kW) or greater with standard ..........
.............. 80 PTO hp (60 kW) or greater with standard ..................
ASAE Category II and III drawbar.
ASAE Category II and III drawbar.
......................All models require two remote hydraulic valves capable of 1500 psi (10343 kPa), 7-pin SAE J560 connector for transport lights .....................
