Setup and assembly
21
Using the wall-mount option
IP Phone and Expansion Module combination can be wall-mounted using
the wall mount template provided.
Adjusting the tilt base
The Expansion Module stand provides a continuous tilt adjustment so the
tilt angle matches the IP Phone stand angle while accommodating
variations in the desk surface. A clamp mechanism is used to unlock and
lock the foot stand angle from wall mount to desktop configuration.
The Expansion Module is tightened by turning the wheel clockwise and loosened
by turning the wheel counter-clockwise.
Turn the wheel clockwise on the back right side (if viewed from the front)
of the Expansion Module to loosen the stand hinge. Adjust the angle of
the IP Phone using the tilt lever. When the IP Phone is set to a preferred
angle, turn the wheel counter-clockwise on the back of the Expansion
Module to tighten the stand hinge and lock the stand at the same angle as
the attached IP Phone.
CAUTION
Do not over tighten the wheel on the Expansion Module.
