28
S1 – first symbol of the status menu
S2 – second symbol of the status menu
S3 – third symbol of the status menu or 21h
S4 – 21h or 00h
Examples of the LRF menu output:
Output, Hex
Output, ASCII
LRF menu
position
53h 54h 31h 21h
0Ah 0Dh
ST1!
Standard 1
43h 4Fh 44h 21h
0Ah 0Dh
COD!
Code
47h 41h 54h 21h
0Ah 0Dh
GAT!
Gating
52h 45h 43h 21h
0Ah 0Dh
REC!
Recall
43h 4Ch 52h 21h
0Ah 0Dh
CLR!
Clear
52h 44h 59h 21h
0Ah 0Dh
RDY!
Position
Ready
43h 31h 21h 00h
0Ah 0Dh
C1!
Code 1
47h 31h 21h 00h
0Ah 0Dh
G1!
Gating over
100 m
