22
Display test mode
Selecting Code 16 in the Setup mode will cause all display
segments and indicators to flash for 8 seconds.
Additional display information
Additional indication is displayed in the Ready to Measure
mode:
Y or M
Indicates that distance is measured and
displayed in yards or meters
KMH or
MPH
Indicates that speed is measured and displayed
in km/h or mph
° Indicates that only azimuth is measured
° Indicates height in meters or azimuth is mils
measured
OVER 100M – indicates that gating is active
Laser active indicator (6, Fig.2) flashes, when unit emits laser
radiation. Reliability of ranging depends on the number of pulses
that reflect from the target and reach the unit. Module informs
user about the number of received pulses by a message on LCD:
TARGET REFLECTION LOW
– ranging results have low
statistical reliability,
TARGET REFLECTION MED – ranging results have
medium statistical reliability,
TARGET REFLECTION HIGH – ranging results have high
statistical reliability.
