21
Data Recall mode
In the Data Recall mode results of the last 10 measurements can
be displayed.
Measurement results are saved in on-board memory in sets
depending on the parameters set for measuring, for instance, if
only distance is measured - the set will consist of one number, if
distance and azimuth are measured – the set will consist of two
numbers.
To enter the Data Recall mode press the M button in the Ready
to Measure mode until
rEc is displayed and then press the A
button. First measurement set number (display name: rEc 1 )
will start flashing.
Pressing the M button moves the unit along the list of
measurement set numbers and measurement results:
rEc 1 , distance 1, azimuth 1, elevation 1,
rEc 2 , distance 2, azimuth 2, elevation 1, …,
rEc 0 , distance 0, azimuth 0, elevation 0.
Measurement sets are numbered in reverse order: first recalled
set is the result of the last measurement. If any parameter has not
been actually measured it will not be recalled.
Pressing the A button at any moment within the list of recalled
results (or pressing the M button at the end of the list) brings the
unit to the Ready to Measure mode.
Choosing
cLr
in the Setup mode will erase all measurement
data.
