Chapter 6: Peripheral Devices & Accessories
Attaching The Hand Strap
178 Psion Teklogix NEO Hand-Held Computer User Manual
6.1.1 Attaching The Hand Strap
The hand strap provides a secure means for operators to carry NEO.
Figure 6.1 The Hand Strap
• Thread the lanyard attached to the quick release buckle through one of the accessory
attachment points – the eyelets on the either side of the base of the unit. You may find
Figure 6.2 useful as a reference.
Figure 6.2 Attaching The Quick Release Buckle
• Guide the quick release buckle through the lanyard loop to secure it to the unit.
Eyelet for Screw
Eyelet for
Attaching Tether
Elastic Strap
Adjustable Velcro
Lanyard
Clasp
Stylus Holder
Quick Release
Buckle
1 2 3
