PANDUIT TDP4*H
GMTDPH-MAN
Page 3-6
Section 3: Configuration
External Signal Type Selection (DSW3-6, DSW3-7). Both the polarity and signal type (level or pulse) of the
external print synchronizing signal can be selected.
Repeat Print via External Signal (DSW3-8). Allows the applicator to reprint the current label in the print buffer.
1
2
3
4
5
6
7
8
DSW1
ON
OFF
DSW3-6
DSW3-7
Off
Off
Off
On
SETTING
Type 4
Type 3
On
Off
Type 2
On
On
Type 1
DSW3
ON
OFF
DSW3-8
SETTING
Off
Enabled
On
Disabled
