PANDUIT TDP4*H
GMTDPH-MAN
Page 3-2
Section 3: Configuration
Stop Bit Selection (DSW1-4). Selects the number of stop bits to end each byte transmission.
Baud Rate Selection (DSW1-5, DSW1-6). Selects the data rate (bps) for the RS232 port.
Protocol Selection (DSW1-7, DSW1-8). Selects the flow control and status reporting protocols. See
Section 6:
Interface Specifications for more information. (* Will select the Status 2 protocol if DSW2-8 is ON).
PRINTER SET UP
Print Mode Selection (DSW2-1). Selects between direct thermal printing on thermally sensitive paper and
thermal transfer printing using a ribbon.
DSW1
ON
OFF
DSW1-4
SETTING
Off
1 Stop Bit
On
2 Stop Bits
DSW2
ON
OFF
DSW2-1
SETTING
Off
Therm Xfr
On
Direct Therm
1
2
3
4
5
6
7
8
DSW1
ON
OFF
DSW1-5
DSW1-6
Off
Off
Off
On
SETTING
9600
19200
On
Off
38400
On
On
57600
1
2
3
4
5
6
7
8
DSW1
ON
OFF
DSW1-7
DSW1-8
Off
Off
Off
On
SETTING
Rdy/Bsy
Xon/Xoff
On
Off
Bi-Com 3
On
On
Bi-Com 4
