33
● Synchronization (SYNC)
1. Display SET UP on the monitor screen.
If necessary, refer to Setup Menu Display on page 16 for details
on displaying the SET UP menu on the monitor screen.
2. Move the cursor to SYNC and select line-lock (LL) or internal (INT)
by using the joystick.
The factory default setting is INT.
Important Notices:
1. The priority of SYNC modes is as follows:
1. Multiplexed vertical drive (VD2) (highest priority)
2. Line-lock (LL)
3. Internal sync (INT) (lowest priority)
2. To use internal sync, select INT.
3. Whenever the vertical drive pulse (VD2) is supplied to the cam-
era, the camera sync mode is automatically switched to the multi-
plexed vertical drive (VD2) regardless which sync mode is select-
ed.
Line-lock Sync Mode (LL)
1. Display SET UP on the monitor screen.
(Refer to Setup Menu Display on page 16 for details on displaying
the SET UP menu on the monitor screen.)
2. Move the cursor to SYNC and select LL by using the joystick. LL
sync mode is not available when the multiplexed vertical drive
(VD2) pulse is supplied.
3. After selecting LL, press the CAM (SET) key.
The SYNC menu appears on the monitor screen.
4. Supply the video output signal of the camera to be adjusted and
the reference camera video output signal to a dual-trace oscillo-
scope.
5. Set the dual-trace oscilloscope to the vertical rate and expand the
vertical sync portion on the oscilloscope.
6. Move the cursor to COARSE by using the joystick.
** SET UP **
CAMERA ID
ALC/MANUAL
SHUTTER
AGC
SYNC
WHITE BAL
AF MODE
EL-ZOOM
IMAGE HOLD
RET SPECIAL
ON
ALC
OFF
ON(MID)
INT
ATW
MANUAL S
ON
OFF
Camera setting menu
** SET UP **
CAMERA ID
ALC/MANUAL
SHUTTER
AGC
SYNC
WHITE BAL
AF MODE
EL-ZOOM
IMAGE HOLD
RET SPECIAL
ON
ALC
OFF
ON(MID)
LL
ATW
MANUAL S
ON
OFF
Camera setting menu
** SYNC **
V PHASE
COARSE
FINE
RET
1(1--16)
•|•••••••
- +
SYNC menu
