Setting up

15

Follow the steps below if your computer has other external

SCSI devices in addition to the DMC camera. You must

install the DMC camera as the last device in your SCSI chain

as follows:

1 Turn off the computer, all SCSI devices, and the camera.

2 Remove the terminator (a) from the last device in your SCSI

chain.

2scsipc.ai

Note: Keep the terminator. You will need to reconnect it if

you wish to use the computer while the camera is

disconnected from it.

3 If necessary for your installation, attach the 25/50 DB to HD

SCSI adapter (b) to the end of the SCSI cable (c).

Use only the cable provided with the camera. Other cables

may appear similar, but could damage the camera or your

computer.

4 Connect the 25/50 DB to HD SCSI adapter (b) to the

connector from which you removed the terminator.

5 If you have not already done so, connect the other end of the

SCSI cable (d) to the SCSI connector on the DMC camera as

shown on page 13.

6 Connect the camera to AC power using the power adapter

(e).

If your PC has other

SCSI devices
