VTrak M-Class Quick Start Guide
6
Figure 6. M300f/i and M200f/i drive carrier mounting holes
Figure 7. SATA Disk Drives mount at the front of the carrier
A VTrak M500f/i/p carrier is shown above. The VTrak M300f/i/p and M200f/i/p
carrier is similar in appearance but the two carrier designs are NOT
interchangeable.
W
ARNING:
C
ount
er-sink scr
ews only
.
PATA-to-SATA
Adapter
SATA Drive Mounting Holes
PATA Drive
Mounting Holes
Serial ATA Disk Drive
