Step 1: Unpack the VTrak
3
Figure 1. VTrak M500f/i/p Front View
Figure 2. VTrak M300f/i/p and M200f/i/p Front View
PROMISE VTrak M500
Power FRU
Status
Logical Drive
Status
FC/iSCSI/
SCSI-1
Activity
FC/iSCSI/
SCSI-2
Activity
Controller
Heartbeat
Power
FC/iSCSI/SCSI-2 Activity
FRU Status
Disk Array Status
FC/iSCSI/SCSI-1 Activity
Controller Heartbeat
