91
Integrator Mode
Screen 1
]
MENU – –
WHITE BALANCE
SCREEN
3ADDITIONAL SET UP
TOTAL INITIALIZE
Screen 2
]
ADDITIONAL SET UP – –
3COLOUR MODE : 1
BAUD RATE : 4800BPS
HOUR METER : 00123
MIRROR MODE : OFF
EXIT
STD-RGB : OFF
SIDE MASK ADJ.
1 Enter Integrator mode (refer to “5.4.1 About Integrator
Mode”).
The ID number of the set of adjustment items will be
indicated in the upper right corner of the screen where “– –
” is displayed in the illustaration.
Select ADDITIONAL SET UP.
2 Move the cursor to COLOUR MODE and select the desired
color mode with the SET button.
Pressing the SET button toggles the color mode between 1
and 2.
COLOUR MODE affects every input (INPUTs 1-4) without
exception. All inputs are immediately switched to the same
color mode when a selection is made in step 3.
Select EXIT in screen 2 to return to screen 1.
4) Setting the Colour Mode
In addition to normal color mode (COLOUR MODE 1), this unit also provides a COLOUR MODE 2, with PICTURE and
WHITE BALANCE parameters preset for maximum performance in picture reshooting in TV studios. Use the mode
appropriate for the situation.
This unit is factory preset to COLOUR MODE 1.
NOTE: The current COLOUR MODE can be identified by the ID display color.
Cyan: COLOUR MODE 1
White: COLOUR MODE 2
