57
Speaker System: PDP-S02-LR
Figure 3
Plasma display ceiling mount bracket
Monitor mount bolt
Washer 25 mm in o.d.
(supplied with optional speaker)
This circle shows the path that the outermost part
of the plasma display follows when it is rotated
about a verticalaxis axis after having been tilted
sideways by 25˚
This circle shows the path that the outermost part
of the plasma display follows when it is rotated
about a verticalaxis axis after having been tilted
sideways by 25˚
Maximum sideways tilt: 45˚
45°
45°
R730°
R689°
