108
RS-232C Adjustment Mode
3) (GET STATUS) — The status of various settings is transmitted in the following formats:
• Output items [Example of output] = Setting status when the signals to the
left are issued
(1) STX (02H)
(2) Version of microcomputer software (5 bytes) [5435A] = Version A
(3) Input function status (3 bytes) [IN1]
= INPUT 1
(4) Color-mode setting status (3 bytes) [CM1] = COLOUR MODE 1
(5) Full auto zoom setting status (3 bytes) [AZN] = Full Auto Zoom: OFF
(6) Screen-size setting status (3 bytes) [SM2]
= Screen-Size Setting: FULL
(7) Auto power off setting status (3 bytes) [APN] = Auto Power Off: OFF
(8) 3-dimensional Y/C Separator Setting Status
(3 Bytes) [ YCM] = 3D Y/C MODE: MOTION
(For U.S. models and Taiwanese models)
(9) COLOUR SYS Setting Status (3 Bytes) [TVA]
= COLOUR SYS: AUTO
(For EURO models only)
(10) Status of connected equipment settings and input signal format settings
(3 bytes) [BBY]
= INPUT SETTING: VIDEO; SIGNAL: RGB
(11) Clamp position setting status (3 bytes) [CL1] = CLAMP: MODE 1
(12) ABL setting status (3 bytes) [ABY] = ABL: ON
(13) MP mode setting status (3 bytes) [MPY]
= MP: ON
(14) KEY LOCK/UNLOCK (3 bytes) [KLN] = UNLOCK (available either from the remote
or the operating panel of the main unit)
(15) OSD display setting status (3 bytes) [DIN]
= OSD not displayed
(16) Mirror mode setting status (3 bytes) [MMZ] = MIRROR MODE: XY
(17) Dummy data (3 bytes)
(18) STD-RGB setting status (3 bytes) [NRY] = STD-RGB: ON
(19) ETX (03H)
NOTES: • Refer to P.74 to P.94 and P.113 for the setting for each item.
• When the input function is INPUT 1, the dummy data is issued for:
(10) Status of connected equipment settings and input signal format settings
(11) Clamp position setting status
(12) ABL setting status
(13) MP mode setting status
• When the input function is INPUT 2, or INPUT 3 or 4 and in the VIDEO setting, the dummy data is issued for:
(8) 3-dimensional Y/C separator setting status
(11) Clamp position setting status
(12) ABL setting status
(13) MP mode setting status
• When the input function is INPUT 3 or 4 and in the PC setting, the dummy data is issued for:
(8) 3-dimensional Y/C separator setting status
