Pioneer PDP-501MX User Manual
Page 35
35
Methods for securing: Basic methods for securing the device are shown below. Avoid blocking or covering areas, aside
from those indicated by
. The method indicated with cross-hatching should be avoided.
Before attaching the unit to fittings, double-check that the thickness and height of the fittings
and the number of fixing bolts is correct. (Also refer to 3.4.1 Mounting to Fittings)
Special Installation (Ceiling-suspension (with wires))
More than 700 mm
More than 700 mm
