– 40 –
Setup menus
The underline on the setting item denotes the initial setting.
USER menu
611 EDH 0000
0001 OFF
ON
This selects whether to superimpose EDH onto the serial
output signals.
0:
1:
• This item setting is valid when the optional serial interface
board has been installed.
EDH is not superimposed.
EDH is superimposed.
Item Setting
No.
Superimposed
display
Description
No.
Superimposed
display
606 CC (F2)
BLANK 0000
0001 BLANK
THRU
This selects ON or OFF for the closed capture signal in the
second field.
0:
1:
608 FREEZE
SEL 0000
0001 FIELD
FRAME
This selects the freeze mode for still pictures.
0:
1:
When frame freeze is selected, the frame freeze mode is
established even during slow motion.
Field freeze
Frame freeze
614 VOUT
SETUP 0000
0001 THRU
ADD
This selects the composite output signal.
0:
1:
The signal is output without setup.
Ths signal is output with 7.5% setup.
613 VIN SETUP 0000
0001 THRU
CUT
This selects whether the composite signal is to be recorded
with setup or without setup.
0:
1:
When recording composite signals, be sure to double-check
whether the signals are to be recorded with or without setup.
When recording signals with no setup.
When recording signals with 7.5% setup.
(continued)
Forced blanking performed.
Blanking not performed.
612 WIDE
SELECT 0000
0001
0002 AUTO
WIDE
NORMAL
This selects the operation to be conducted in response to the
WIDE information.
0:
1:
2:
This item is effective during recording at the start of the
recording and during playback at all times. Therefore, when
its setting has been changed during recording, the MENU
contents will be changed but no change will occur in the
actual operation.
During recording, if the Y/C input signals contain WIDE
information, the WIDE information is recorded on the tape.
During playback, if WIDE information is on the tape, it is
added to the Y/C output signals.
During recording, the WIDE information is recorded on the
tape regardless of whether the Y/C input signals contain
the WIDE information.
During playback, the WIDE information is added to the
Y/C output signals regardless of whether the WIDE
information is on the tape.
→
Forced WIDE ON
During recording, the WIDE information is not recorded on
the tape regardless of whether the Y/C input signals
contain the WIDE information.
During playback, the WIDE information is not added to the
Y/C output signals regardless of whether the WIDE
information is on the tape.
→ Forced WIDE OFF
