Page 57
57
Specifications
● General Specifications
● HDD (One HDD is provided at the factory. Contact your dealer to purchase additional HDD.)
● Input/output
*1
No voltage make contact input +5 V pull-up, 150 k
Ω
*2
Maximum output of open collector is DC 24 V, 100 mA
*3
High (+5 V to +12 V, max. 6.3 mA)
*4
52 k
Ω +5-V pull-up, output current -100 mA, no voltage make contact input
*5
Max. 200 mA
WJ-ND400
Power source
NTSC model: 120 V AC, 60 Hz
PAL model: 220 V - 240 V AC, 50 Hz
Power consumption
170 W
Ambient operating
temperature
+5 ºC to +45 ºC {41 °F - 113 °F}
Ambient operating
humidity
5 % to 90 % (non condensing)
Maximum operating
altitude
2 000 m {6 562 feet} above sea level
Dimensions
430 mm (W) x 132 mm (H) x 400 mm (D) {16-15/16" (W) x 5-3/16" (H) x15-12/16" (D)}
(excluding rubber feet and projections)
Weight
When 1 HDD is
installed
14
kg {30.9 lbs}
When 9 HDDs are
installed
20
kg {44.15 lbs}
HDD
Type/function
3.5" HDD x 1(Up to 9 HDDs)
RAID5 mode available (only when 3 or more HDDs are installed)
RAID6 mode available (only when 4 or more HDDs are installed)
External storage
High-speed serial interface, 1.5 Gbps (theoretical value), x5
Alarm/Control connector
Alarm input 8-16
*1
, Network error output
*2
, Alarm reset input
*1
,
Emergency recording input
*1
, Available disk space warning output
*2
, HDD error output
*2
,
Camera error output
*2
, Error output
*2
, Power outage recovery completion output
*3
, Time
adjustment input/output
*4
, Alarm output
*2
,
Alarm suspension input
*1
, Power outage detection input
*1
, External recording mode
switching
*1
, +5 V output
*5
(D-sub 25-pin)
Alarm connector
Alarm input 1-7
*1
, Alarm input 17-32
*1
(D-sub 25-pin)
Client PC port
10BASE-T/100BASE-TX/1000BASE-T (RJ-45)
Camera port
10BASE-T/100BASE-TX/1000BASE-T (RJ-45)
Maintenance port
10BASE-T (RJ-45)
