32
Connecting the Telephone Line Cables and Power Cord
Power Cord
Plug one end of the power cord into an ordinary 3 prong AC outlet and the other end into the receptacle on the
rear of the machine.
Warning : This apparatus must be properly grounded through an ordinary 3 prong AC outlet.
Do not break off the earth (ground) prong to fit a 2 prong outlet.
(see Note 1)
Telephone Line Cable
Plug one end of the telephone line cable into the "RJ-11C" telephone jack supplied by the telephone company
and the other end into the LINE jack on the left side of the machine.
1. Your machine uses little power and you should keep it ON at all times.
Ethernet-Token-Ring
Bridge
(Optional Order
No. UE-204006)
10Base-T Ethernet Hub
Ethernet LAN (10Base-T) Cable (Not included)
Power Cord (Included)
Telephone Line Cable (Included)
RJ-11C Telephone Jack
Note:
