Setup, Diagram of connections, Cable/xdsl modem connection – Panasonic KX-HGW200 User Manual
Page 12: Power source, Wireless network homepna phone line network, Ethernet connection
12
Setup
Cable/xDSL modem
Category 5
straight cable
Telephone
(
‘
p. 16)
Telephone
jack
AC adaptor
Telephone line
cord
Power outlet
Cable/xDSL
modem connection
(
‘
p. 14)
Power source
(
‘
p. 19)
Wireless network
HomePNA phone
line network
(
‘
p. 15)
Ethernet connection
(
‘
p. 17, 18)
Optional
wireless card
(KX-HGC200)
Telephone
jack
Telephone line
cord
Telephone
jack
Category 5
straight cable
Diagram of Connections
PQQX12817ZA \1-P29
01.3.8
3:17
PM
y [ W 12
