2.11 Starting the PBX
100
Installation Manual
2.11 Starting the PBX
2.11.1 Starting the PBX
CAUTION
•
SD Memory Card must be inserted in the SD Memory Card slot of the main board before start up.
•
Before touching the System Initialize Switch, discharge static electricity by touching ground or
wearing a grounding strap.
•
Once you have started the PBX and if you unplug the PBX, do not perform the following procedures
to start the PBX again. Otherwise, your programmed data is cleared. To restart the PBX, refer to
"4.1.4 Using the Reset Button".
•
The PBX will continue to be powered even if the power switch is turned "OFF".
•
The power supply cord is used as the main disconnect device. Ensure that the AC outlet is located
near the equipment and is easily accessible.
1.
Set the System Initialize Switch to the "SYSTEM INITIALIZE" position.
RUN Indicator
ALARM Indicator
Reset Button
System Initialize Switch
