37

Connecting the signal source to the input module for serial digital signals

SD

signal

SD signal output

(Active through)

Serial digital input module(sold separately)

MAIN IN

Professional-type

digital VCR

ET-MD95SD2 (for 480p/480i/576i)

480p Module

ET-MD95SD2

SERIAL

MAIN OUT

SUB IN

SUB OUT

MAIN

(Link-A)

SUB

(Link-B)

MAIN

(Link-A)

SUB

(Link-B)

1. 480p dual link (4:2:2p): 59.94 Hz progressive scan with 720 by 483 active lines at

270 Mbps, complying with the SMPTE294M Standard
