Page 85
17 Replacement Parts List (Outdoor Unit)
17.1. CU-E15DBE CU-E18DBE CU-E21DBE
REF NO.
DESCRIPTION & NAME
QTY.
CU-E15DBE
CU-E18DBE
CU-E21DBE
REMARKS
1
CHASSY ASSY
1
CWD50K2085
←
←
2
ANTI-VIBRATION BUSHING
3
CWH50077
←
←
3
COMPRESSOR
1
5CS130XAD04
←
←
O
4
NUT-COMPRESSOR MOUNT
3
CWH56000
←
←
5
SOUND PROOF MATERIAL
1
CWG302302
←
←
6
FAN MOTOR BRACKET
1
CWD541084
CWD541054
←
7
FAN MOTOR
1
CWA981166
←
←
O
8
SCREW - FAN MOTOR BRACKET
2
CWH551060
←
←
9
SCREW - FAN MOTOR MOUNT
3
CWH551106
←
←
10
PROPELLER FAN ASSY
1
CWH03K1016
←
←
11
NUT - PROPELLER FAN
1
CWH56053
←
←
12
CONDENSER
1
CWB32C1583
CWB32C1527
CWB32C1526
14
TUBE ASS
’
Y COMPLETE (CAP TUBE/EXP.VALVE)
1
CWT023679
←
CWT023610
O
15
4 WAYS VALVE
1
CWB001026
←
←
16
STRAINER
1
CWB11094
←
←
18
HOLDER - COUPLING
1
CWH351035
←
←
19
3 WAYS VALVE (GAS)
1
CWB011170
←
←
O
20
2 WAYS VALVE (LIQUID)
1
CWB021292
←
CWB021306
O
22
SOUND PROOF BOARD
1
CWH151050
←
←
23
TERMINAL COVER
1
CWH171001
←
←
24
NUT-TERMINAL COVER
1
CWH7080300
←
←
25
SENSOR COMPLETE (COMP. TOP)
1
CWA50C2185
←
←
26
HOLDER SENSOR
1
CWH321010
←
←
27
V-COIL COMPLETE (4-WAYS VALVE)
1
CWA43C2168
←
←
28
V-COIL COMPLETE (EXPAND VALVE)
1
CWA43C2141
←
←
29
SENSOR COMPLETE (COMP. DISC.)
1
CWA50C2180
←
←
30
SENSOR COMPLETE
1
CWA50C2181
←
←
31
REACTOR
1
CWA421069
←
←
32
CONTROL BOARD CASING (SIDE)
1
CWH102273
←
←
33
TERMINAL BOARD ASSY
1
CWA28K1110
←
←
34
FUSE HOLDERS
1
K3GB1PH00016
←
←
35
FUSE
1
K5D303BBA002
←
←
36
CONTROL BOARD CASING (TOP)
1
CWH102204
←
←
37
CONTROL BOARD CASING (BOTTOM)
1
CWH102282
←
←
38
ELECTRONIC CONTROLLER - MAIN
1
CWA73C1767R
CWA73C1768R
CWA73C1769R
O
40
CONTROL BOARD COVER (TOP)
1
CWH131167
←
←
41
CABINET SIDE PLATE (LEFT)
1
CWE041082A
←
←
42
HANDLE
1
CWE161010
←
←
43
CABINET SIDE PLATE (RIGHT)
1
CWE041083A
←
←
44
HANDLE
2
CWE16000E
←
←
45
CABINET FRONT PLATE CO.
1
CWE06K1043
←
←
46
WIRE NET
1
CWD041041A
←
←
47
CABINET TOP PLATE
1
CWE031031A
←
←
48
CONTROL BOARD COVER (BOTTOM)
1
CWH131168
←
←
49
CONTROL BOARD COVER (TOP)
1
CWH131169A
←
←
50
OPERATING INSTRUCTION
1
CWF564379
←
←
51
OPERATING INSTRUCTION
1
CWF564380
←
←
52
INSTALLATION INSTRUCTION
1
CWF612604
←
←
53
INSTALLATION INSTRUCTION
1
CWF612605
←
←
54
INSTALLATION INSTRUCTION
1
CWF612606
←
←
56
DRAIN HOSE
1
CWH5850080
←
←
57
PACKING
1
CWB81012
←
←
58
SOUND PROOF MATERIAL
1
CWG302290
CWG302270
←
59
SOUND PROOF MATERIAL
1
CWG302301
CWG302300
←
(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
• “O” marked parts are recommended to be kept in stock.
85
CS-E15DB4EW CU-E15DBE / CS-E18DB4EW CU-E18DBE / CS-E21DB4ES CU-E21DBE
