DVR User’s Manual
33
To configure the dome controls settings, see the following sections.
4.5.1 Dome Connection
Follow the steps to install dome camera.
• See
Setup Guide for RS-485 port pin definition.
• Connect the R+, R- terminals on the dome camera to the D+, D- terminals
on the RS-485 port by RS-485 cable respectively. Refer to the connection
figure illustrated in Setup Guide.
4.5.2 Dome Protocol Setup
The Dome Protocol item lists the available dome protocols for communicating
with dome cameras connected to the DVR series unit. From the Main menu,
select and press ENTER. The following menu is displayed.
Analog Camera
1. Analog Camera Select
2. Dome Protocol
3. Dome ID
4. Camera Title
5. Covert
6. Brightness
7. Contrast
8. Saturation
9. Hue CH1
None
0
NO
0
0
0
0
To configure dome protocol, select a camera first and set the communications
protocol associated with dome camera using the Direction keys and ENTER.
The available protocol includes , , ,
, , , , , and
(default).
NOTE:
The settings become effective after saving the changes and
exiting from the menu.
