Console port connector – Paradyne BitStorm 2600 IP DSLAM User Manual
Page 49
A. Connectors and Pin Assignments
2600-A2-GN20-10
January 2004
A-5
Console Port Connector
The CONSOLE port connector is a DB9 socket connector that supports an
EIA-232-E circuit as shown in
Table A-5
.
Table A-5.
Console Port Connector
RS-232 Signal
Direction
Pin
Data Carrier Detect
Out
1
Receive Data
Out
2
Send Data
In
3
Data Terminal Ready
In
4
Ground
—
5
Data Set Ready
Out
6
Request to Send
In
7
Clear to Send
In
8
Ring Indicator
—
9
