2. Cabling

2-6

January 2004

2600-A2-GN20-10

Management Port

Port 1 can be used to connect the BitStorm 2600 to a network management
system using a 10BaseT or 100BaseT LAN. A straight-through cable can be used
regardless of the destination interface, since the port automatically distinguishes
between an MDI and an MDIX.

Procedure

To use Port 1 as the out-of-band management port:

1. Connect an 8-position modular cable to Port 1.

2. If the BitStorm 2600 is in a rack, fasten the cable to a rail with a cable tie.

3. Connect the other end of the cable to your Ethernet hub or to a network

interface card in a PC.

03-17446

Hub Device

Port 1

PORT1-10/100BT

CONSOLE

PORT2-10/100BT

PORT3

L

IN

K

A

C

T

GigE

S

TA

T

U

S

A

LA

R

M

TE

S

T

ALARM

1

2

23

DSL POR

TS 1-24

1000BT

24

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22
