1. Installation

1-2

January 2004

2600-A2-GN20-10

BitStorm 2600 IP DSLAM models and features are listed in

Table 1-1, BitStorm

2600 Models and Features

.

Preparation

Consider the following before installing the BitStorm 2600 IP DSLAM:

„

Installation Site

Your installation site should be well ventilated, clean, and free of
environmental extremes.

„

Installation Options

The BitStorm 2600 may be:

— Mounted with the included mounting brackets in a standard 19-inch

(483 mm) or 23-inch (584 mm) rack (including both Bay Networks and
Nortel 23-inch racks), or, with separately purchased mounting brackets, in
a 21-inch (535 mm) ETSI rack. ETSI brackets are available from
Paradyne. See

Appendix B, Equipment List

.

As many BitStorm 2600 units may be mounted in a standard rack as there
are 1.75-inch (44.45 mm) spaces in the rack, so long as adequate cooling
is provided.

— Mounted vertically against a wall.

The standard mounting brackets provided can be fastened to the base of
the unit for wall mounting.

— Set on a shelf or desktop.

Up to five BitStorm 2600 units may be stacked on a shelf or desktop.
Different models can be mixed in a stack.

„

Power

The BitStorm 2600 operates from a 90 to 265 VAC, 47 to 63 Hz power source.

„

Other Cabling

No cables are provided with the BitStorm 2600. See

Table 1-2, Cable

Descriptions

, to determine what cables you need to procure before

installation.

Table 1-1.

BitStorm 2600 Models and Features

Model Number

Type

Number of Ports POTS Splitters

2611-A1-420

ReachDSL

24

No

2611-A1-430

ReachDSL

24

Yes

2621-A1-420

ADSL

24

No

2621-A1-430

ADSL

24

Yes
