A8 hull and body – Polaris VIRAGE W005197D User Manual
Page 8
A8
HULL and BODY
VIRAGE W005197D and INT’L VIRAGE W005197I
Ref. Part No.
Qty.
Description
Ref. Part No.
Qty.
Description
1 5811915-070
1 Pad, Boarding Platform
2 5811913-070
5811914-070
1
1
Pad, Footwell, Rear, LH
Pad, Footwell, Rear, RH
3 5811911-070
5811912-070
1
1
Pad, Footwell, Center, LH
Pad, Footwell, Center, RH
4 5811909-070
5811910-070
1
1
Pad, Footwell, Front, LH
Pad, Footwell, Front, RH
5 5411158
2 Grommet
6 5411658
1 Grommet
7 7516807
2 Screw
8 7556094
14 Washer
9 5433671
1 Plate, Seat Tongue
10 7546704
8 Nut
11 5411758-070
1 Bumper, Front
12 7621511
31 Rivet
13 5431994-070
29 Plug, Bumper, Rear
14 7542133
4 Nut, Nylok
15 7555839
12 Washer
16 7555870
2 Washer, Dish, Rubber
17 2670150
1 Strap, Bow
18 5521568-070
5521569-070
1
1
Rail, Rub, Side, LH
Rail, Rub, Side, RH
19 5811440
10 Washer
20 5432272-070
5432273-070
1
1
Sponson, LH
Sponson, RH
21 7515198
10 Bolt
22 7517320-070
2 Bolt
23 7555836
2 Washer
24 5811918
5811919
1
1
Pad, Heel, LH
Pad, Heel, RH
25 5433531-070
1 Bumper, Rear
26 1060125
2 Plug, Bilge
27 7511882
4 Screw
28 2632218
1 Hook, Tow
29 7517644
6 Screw
30 7555846
2 Washer
31 7542454
2 Nut
32 5020753
1 Plunger, Latch
33 5433474-070
1 Handle, Grab
34 7552607
1 Washer, Lock
35 5433473
1 Bucket, Rear Storage
4/00
