TROUBLESHOOTING
EATON Powerware
®
Modbus
®
Card User’s Guide
S 164201376 Rev C www.powerware.com
24
1
J11
2
1 3 4 5 6
O N
S2
J7 J8
J10
J9
S2
Termination
(Default ”OFF”)
J11
Half Duplex
Full-Duplex
(Default)
1
1
J9
J10
Two-Wire
(Default)
1
1
Two-Wire/Four-Wire
J7 J8
DCE
DCE/DTE
(Default)
1
1
Figure 15. Modbus Card Default Jumper Settings
