REF. PART DESCRIPTION
NO. NO.
40G 0006650 Assembly, I/C wires 1 1
40G 0006510 Assembly, I/C wires 1 1
41 0050426 Solenoid 1 1
42 0050425 Wire, solenoid 1 1
44 Note B Screw 8-32 x 3/8 4 4
54 0050941 Bracket, muffler 1 1
55 0051879 Muffler, 5.5 hp 1 1 1
55 0050952 Muffler, 9 hp 1 1
56 0051880 Gasket, muffler 1 1 1
56 0051634 Gasket, muffler 1 1
56 0036079 Solenoid, starter 1
57 0047783 Nut, hex M8 x 1.25 2 2 2 2 2
58 0052931 Clamp, vinyl 1/2” 1 1 1 1 1
58 0012526 Bolt, 1/4-20 x 3/4 1 2
59 0052627 AVR 1 1 1 1
* 0051291 Assembly, battery cable 1 1 1
Note A: Coleman Powermate will not provide engines as replacement parts. Engines are covered through the engine
manufacturer’s warranty. Consult the accompanying engine manual or contact our service department for assistance.
Note B: These are standard parts available at your local hardware store.
Note C: Contact your nearest Coleman Powermate Service Center for replacement fuel tanks.
*
These items are not shown.
WARNING: To avoid possible personal injury or equipment damage, a registered electrician or an
authorized service representative should perform installation and all service. Under no circumstances
should an unqualified person attempt to wire into a utility circuit.
Electrical: For city of Los Angeles approved models (PL’s) the ampacity of the phase conductors from the generator terminals
to the first over current device shall not be less than 115 percent of the nameplate rating of the generator.
37 English
