Powermate Vantage Series PC0473503 - Manual (Page 36)

REF. PART DESCRIPTION
NO. NO.
22 0049279 Bolt, wz 5/16-18 x 1/2 2 2 2 2 1 1 3 3 3 1
23 0048736 Nut, nyloc 5/16-18 7 7 7 5 9 9 6 6 6 6
24 0050346 Panel, end 47-7 1 1 1
24 0053019 Panel, end 47-8 1
25 Note B Washer, flat 5/16 9 9 9 10 15 15 11 11 9 10
26 Note B Bolt, 5/16-18 x 1 1/2 1 1 1 3 1 1 2 2 3
26 Note B Bolt, 5/16-18 x 1 1/4 4
27 0050334 Bracket, stator support 1 1 1
27 0055620 Washer, .42 x 1.5 x .25 2
28 0049224 Assembly, ground wire 1 1 1 1 1 1 1 1 1 1
29 Note B Washer, star external 5/16 2 2 2 3 2 2 3 3 4 3
30 Note B Bolt, hex 5/16-18 x 3/4 1 1 1 1 1 1 1 1 1
30 Note B Bolt, hex 5/16-18 x 1 2
31 Note B Bolt, whz 5/16-18 x 1 1 1 1
31 Note B Bolt, hex 1/4-20 x 1 1/2 1
31 Note B Bolt, hex 5/16-18 x 2 1/4 1 1
32 0048586 Spacer, 7/16 1 1 1
32 0047796 Spacer, 3/4 1 2 2
32 Note B Screw, 10-32 x 1/2 1 1 1
33 Note B Washer, star no. 10 1 5 5
34 0055181 Shield, heat 1 1 1
34 0051537.01 Shield, heat 1
34 0051821.01 Shield, heat 1 1
35 0050333 Assembly, deflector 1
35 0050431 AssemblY, deflector, I.C. 1 1
35 0052158 Deflector, heat 1
36 Note C Fuel tank assembly 1 1 1 1 1 1 1 1 1 1
36A 0055340 Cap, fuel 1 1 1 1 1 1 1 1 1 1
36B 0049842 Fuel valve with bushing 1 1 1
36B 0051367 Fuel valve with bushing 1 1
36B 0049114 Fuel valve with bushing 1 1 1 1 1
37 0049920 Fuel, shut-off, in line 1 1 1 1 1
37 0047790 Fuel filter 1 1 1 1
37A 0051102 Fuel filter 1 1 1
38 0048243 Bushing, step 4 4 4 4 4 4 4 4 4 4
40 0051745 Panel, wired complete 47-3.5 1
40 0052308 Panel, wired complete LA 1
40 0051982 Panel, wired complete CSA 1
40 0055663 Panel, wired complete 47-4.2 1
40 0051823 Panel, wired complete 47-5 1
40 0050518.03 Panel, wired complete CSA 1
40 0050336 Panel, wired complete 47-7 1
40 0050435.01 Panel, wired complete 47-7 1
40 0051288 Panel, wired complete CSA 1
40 0052930 Panel, wired complete 47-8 1
40A 0049070 Circuit breaker, 15 amp 2 2
40A 0048067 Circuit breaker, 15 amp 2 1
40A 0049071 Circuit breaker, 20 amp 1 1 1
40A 0049072 Circuit breaker, 25 amp 2
40A 0051763 Circuit breaker, 20 amp 2 2
40B 0049382 Circuit breaker, 30 amp 1 1 1 1 2
40B 0048337 Circuit breaker, 35 amp 1 2 2 2
40C 0050298 Switch 1 1 1 1 1
40C 0049248 Switch, dual rocker 1
40C 0047776 Switch w/light 1 1
40C 0036137 Switch, rotor, key 1
40D 0048900 Strain relief 1
40F 0050625.01 Module, idle control 1 1 1 1 1 1 1 1
40G 0006667 Assembly, I/C wires 1 1 1
40G 0055672 Assembly, I/C wires 1
P
M
04
7
35
03
P
M
04
74
20
3
P
L0
47
3
50
3
P
C
04
7
35
03
P
M
04
75
0
03
P
C
04
75
00
3
P
M
04
7
70
22
P
M
04
7
70
23
P
C
04
77
02
3
P
M
04
78
0
22
36 English
