Powermate Vantage Series PC0473503 - Manual (Page 35)

REF. PART DESCRIPTION
NO. NO.
1 Note A Engine, 5.5 hp Vanguard, OHV 1 1 1
1 Note A Engine, 8 hp Robin, OHV 1
1 Note A Engine, 9 hp Vanguard, OHV 1 1
1 Note A Engine, 14 hp Vanguard, V-Twin OHV 1 1 1
1 Note A Engine, 18 hp, Opposed-Twin 1
2 0048685.01 Adapter, engine 1 1 1
2 0050236.01 Adapter, engine 1 1 1 1 1 1 1
3 0000901.01 Bolt, wz 5/16-24 x 5/8 4 4 4
3 0000919.01 Bolt, wz 3/8-16 x 3/4 4 4 4 4 4 4 4
4 0051874 Rotor, 3.0 KW RF 5 1 1 1
4 0049620 Rotor, 5.0 KW RF 5 1 1 1
4 0049623 Rotor, 7 KW B/S RF 5 1 1 1
4 0052293 Rotor, 8 KW, 60 HZ 1
5 Note B Washer, lock 5/16 3 3 3 4 4 4 3 3 3 5
6 0035055 Bolt, hex 5/16-24 x 6 5/8 1 1 1 1 1 1
6 0046540.03 Bolt, hex 5/16-24 x 9 1 1 1
6 0052297 Bolt, hex 5/16-24 x 9 1/4 1
7 0051871 Stator, 3.0 KW, 60 HZ 1 1
7 0051928 Stator, 3.0 KW, 60 HZ, CSA 1
7 0055669 Stator, 4.2 KW, 60 HZ 1
7 0050299 Stator, 5.0 KW, 60 HZ, I.C. 1
7 0050517 Stator, 5.0 KW, 60 HZ, CSA 1
7 0050350 Stator, 7.0 KW, 60 HZ 1
7 0050436 Stator, 7.0 KW, 60 HZ, I.C. 1
7 0050950 Stator, 7.0 KW, 60 HZ, CSA 1
7 0053057 Stator, 8.0 KW, 60 HZ 1
8 0049835 Connector, hsg. set, endbell 1 1 1 1 1 1 1 1 1 1
9 0049200 Connector, hsg. set, panel 1 1 1 1 1 1
9 0050400 Connector, hsg. set, panel 1 1 1 1
10 0050237.01 Endbell, wired 1 1 1 1 1 1
10 0050511.02 Endbell, wired CSA 1 1 1 1
10A 0050439 Brush, E-4R 2 2 2 2 2 2 2 2 2 2
10B 0035188 Bearing, needle FTT-1212 1 1 1 1 1 1 1 1 1 1
10C 0034819.01 Capacitor 1 1 1 1 1 1 1 1 1 1
10D 0034843 Diode 2 2 2 2 2 2 2 2 2
10D 0006296 Diode Assembly 2
10E 0038976 Heat sink, diode 1 1 1 1 1 1 1 1 1 1
10F 0048844 Brush cover 1 1 1 1 1 1 1 1 1 1
11 0051872 Bolt, hex hd 1/4-20 x 4 1/2 4 4 4
11 0040816 Bolt, hex hd 1/4-20 x 6 4 4 4
11 0035170 Bolt, hex hd 1/4-20 x 8 4 4 4 4
12 0008854 Lug, ground 1 1 1 1 1 1 1 1 1 1
13 Note B Washer, flat 1/4 7 7 7 7 7 7 11 11 11 13
14 Note B Washer, star external 1/4 1 1 1 1 1 1 1 1 1 1
15 0040832 Nut, nyloc 1/4-20 12 12 12 13 12 12 14 14 17 20
16 0051680 Carrier, assembly, full 1 1 1
16 0055658 Carrier, assembly, full 1
16 0051756 Carrier, assembly, full 1 1
16 0050345 Carrier, assembly, full 1 1 1
16 0053056 Carrier, assembly, full 1
17 0048837 Cap, plastic 4 4 4 4 4 4 4 4 4
19 0052185 Isolator, engine 2 2 2 2
19 0051094 Isolator, engine 2 2 2 2 4
20 0051094 Isolator, stator 2 2 2 2 2 2 2 1
20 0052210 Isolator, stator 2 2
21 0050134 Bracket, stator 1 1 1 1
21 0049693 Bracket, stator 1 1 1 1 1
21 0048866 Bracket, stator 1
VANTAGE SERIES PARTS LIST
