A Logical, Intuitive Layout
Viewfinder: Slides and tilts upward.
Large eyecup
Jog dial: To control shutter speed,
manual aperture, and menu selection Auto/manual focus button,
white balance button
User buttons 2 and 3: Assignable (user
button 1 is on the hand grip)
SNS button:
Zero Lux IR Mode On/Off
3.5-inch
LCD
Lens hood: Resilient
elastomer
(synthetic rubber)
Auto/Manual
switch
Zoom lever Built-in Stereo mic
Terminals for headphone, digital interface,
and camera remote. Split cover allows
access to headphone terminal only. S-Video In/Out, Mic In/Out, AV In/Out, XLR
Adapter terminals (XLR Adapter can be
used with cover attached)
REC Start/Stop button:
Convenient when using
a tripod or for low-angle
shooting
Power On/Off, CAM/VTR selector,
REC Start/Stop
Buttons that are
used less are set
inside
the LCD panel
User button 1: assignable
Detachable handle: Quick, secure and
easy detachment – no tools required
