14
Switch S2-6: Response to RDL Request from DTE
Use switch S2-6 to determine the Model 1082 response to RDL requests
from the local DTE. In the enabled setting, the 1082 responds to RDL
requests from the local DTE by sending an RDL loop request to the
remote Model 1082 (See “Remote Digital Loopback (RDL)” on page 23).
Switch S2-7: Compatability Mode
In some instances, you may need to connect a Model 1082 to a third
party IDSL modem. By enabling S2-7 the 1082 will negotiate and link up
to a non-Patton IDSL Modem. When using two Patton units, set 2-7 to
the default position.
Switch S2-8: Not Assigned
S2-3 Activation Description
Off Disabled Ignore Remote Digital Loopback request from
DTE interface
On Enabled Respond to Remote Digital Loopback request
from DTE interface
S2-7 Activation Setting
Off Disabled Default position
On Enabled Compatibility Mode
